FM-E2701D, FM-E2701DG 4K UHD Medical Grade Monitor

The FM-E2701D series display monitors offer ultra-clear viewing of endoscopic, fluoroscopic, ultrasound, or other live surgical video content. Rapid signal detection of video sources found in the OR, plus extensive built-in timing tables are the keys to this model’s compatibility.

These units have settings that allow for flexible screen layouts, such as picture-by-picture, using separate video signals. They are solid, yet economical, performers that have all of the features needed in today’s OR.

    • Outstanding image clarity and color reproduction
    • BT.709 and BT.2020 compatible
    • Image rotate (90, 180, 270) and mirror (horizontal, vertical)
    • Full edge bumper guard
    • HDMI, DisplayPort, 3G/12G SDI connections (FM-E2701DG)
Item Description
Panel 27 inch LCD (LED)
Resolution 3840 x 2160 pixels
Active Area 596.16 (H)mm x 335.34 (V)mm
Pixel Pitch (mm) 0.15525 x 0.15525
Response Time (typical) < 16 ms (rise + fall time)
Pixels Arrangement RGB vertical stripes
Number of Colors 1.07 Billion
Brightness (typical) 700 cd/m2
Color Gamut BT.709 and BT.2020 compatible
Contrast Ratio (typical) 1,000 : 1
Surface Treatment Anti-reflection
Viewing Angle (CR>10) R/L 178°, U/D 178°
Input Signal FM-E2701D 2 x HDMI 2.0, 1 x DP 1.4 (SST)
Input Signal FM-E2701DG 2 x HDMI 2.0, 1 x DP 1.4 (SST), 2 x SDI (3G, 12G)
Output Signal FM-E2701D 1 x HDMI 2.0
Output Signal FM-E2701DG 1 x HDMI 2.0, 2 x SDI (3G, 12G)
Power Input AC/DC Adaptor (AC 100~240V, DC 24V/6.6A)
Power Output DC Output (1 x 12V/2A, 1 x 5V/2A)
Power Consumption FM-E2701D 110W max
Power Consumption FM-E2701DG 130W max
Accessories Included User manual, AC-DC adaptor, AC power cord, DP cable, HDMI cable, SDI cable (FM-E2701DG), M4 screws.
Latency (typical) 1 ms
Unit Dimension 671(W) x 423(H) x 74.2(D) mm, 26.42(W) 16.65(H) 2.92(D) inch
Package Dimension 755.65(W) x 654.05(H) x 234.95(D) mm, 29.75(W) x 25.75(H) x 9.25(D) inch
IP Rating IP33 - overall
Weight FM-E2701D 9.17 kg, 20.21 lbs. (monitor with cover), 13.7 kg, 30.2 lbs. (shipping package)
Weight FM-E2701DG 9.40 kg, 20.72 lbs. (monitor with cover), 14.1 kg, 30.08 lbs. (shipping package)
Certifications ANSI/AAMI ES60601-1(UL60601-1), CAN/CSA C22.2 No. 60601-1, FCC Class B, EN60601-1, EN60601-1-2, CE, MDR(EU) 2017/745 Class I Medical Device
